Features主要特點
● Single point load cell
● Senior alloy steel
● High accuracy
● High stability
● Easy to install
● Protected against corrosion by nickelplated treatment
● High protection class
● Use in tough industrial environment
Capacities量程
● 10,20,50,100,200,500N
Specification 技術參數
|
參數
|
Specifications
|
技術指標/Technique
|
|
額定容量
|
Capacity
|
10,20,50,100,200,500N
|
|
輸出靈敏度
|
Rated output
|
2.0±10%mV/V
|
|
零點輸出
|
Zero balance
|
±0.02mV/V
|
|
非線性
|
Non-linearity
|
≤0.05%F.S.
|
|
Hysteresis
|
Hysteresis
|
≤0.05%F.S.
|
|
重複性
|
Repeatability
|
≤0.05%F.S.
|
|
Creep
|
Creep(30min)
|
≤0.05%F.S.
|
|
溫度靈敏度漂移
|
Temp.effect on output
|
0.05%F.S./10℃
|
|
零點溫度漂移
|
Temp.effect on zero
|
0.05%F.S./10℃
|
|
輸入電阻
|
Input impedance
|
650/350±5Ω
|
|
輸出電阻
|
Output impedance
|
650/350±5Ω
|
|
絕緣電阻
|
Insulation
|
≥5000MΩ/100VDC
|
|
工作電壓
|
Recommended excitation
|
5V
|
|
最大工作電壓
|
Maximum excitation
|
15V
|
|
溫度補償範圍
|
Compensated temp range
|
-10~60℃
|
|
工作溫度範圍
|
Operation temp range
|
-20~80℃
|
|
安全超載
|
Safe overload
|
150%F.S.
|
|
極限超載
|
Ultimate overload
|
200%F.S.
|
|
電纜線尺寸
|
Cable size
|
φ2x3000mm
|
|
